Hot!!! JSI-3000TL Grid-tied Solar Inverter

FOB Reference Price:Get Latest Price
US $470-494 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
JFY
Model Number:
JSI-3000TL
Output Power:
1 - 200KW
Output Type:
Single
Size:
345*162*384 mm
Weight:
17KG
Input Voltage:
Max.500Vdc
Output Voltage:
230Vac/220Vac
Type:
DC/AC Inverters
Output Frequency:
50Hz/60Hz
Output Current:
13A
Max. DC power:
3660W
MPPT Operating range:
100~450Vdc
Inverter:
Inverter 3KW
Max.Efficiency:
97.5%
MPPT Efficiency:
99.6%
Max. Output Power:
3400w
N.W.:
15KG
Protection:
IP65
Communication:
RS232/RS485
Nominal Output Current:
13A
Supply Ability
Supply Ability:
6000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
International export standard packing.
Port
main port of China/Shenzhen Port
Lead Time :
7days upon receipt of payment/depends on stock level

JFY On-grid InverterModels:

Single phase with 1 MPPT: JSI series 1.1KW, 2KW, 2.5KW, 3KW, 3.6KW, 5KW, 6KW;

SIngle Phase with 2 MPPT: Suntwins 3.3KW, 4KW, 5KW;

Three phase with 2 MPPT: 5KW, 6KW, 8KW, 10KW, 12KW, 15KW, 17KW,  20KW, 30KW;

Three phase with transformer: 50KT,75KT,  100KT, 150KT, 175KT, 250KT, 500KT, 630KT;



3KW pv inverter


JSI-3000TL

JSI BENEFITS

  •             Compact size and high power density
  •             High speed MPPT for real time power tracking and improved energy harvesting
  •             Transformerless operation for highest efficiency: > 96.7% (>95.5% Euro)
  •             High overload capability: works up to 4000W under most ambient conditions
  •             Certified grid connected operation according to the international standards
  •             True Sine Wave Output
  •             Integrated RS-485/RS-232 serial communication
  •             Multi-language display





JSI-3000TL

Input Data(DC side)

Max. DC power

3660W

Max. DC voltage

500Vdc

MPPT Operating range

100~450Vdc

Number of parallel inputs

2

Number of MPPT trackers

1

Max. input current (total)

20A

Output Data(AC side)

Nominal output power

3000W

Max. Output power

3400W

Nominal output current

13A

Max. output current

15.7A

Nominal AC voltage

230Vac

AC voltage range *

190~265Vac

Nominal AC grid frequency

50Hz

AC grid frequency range*

50 ± 5 Hz

Power factor(cos φ)

>0.99

Harmonic distortion(THDI)

<3%(at nominal output power)

Efficiency

Max. efficiency

>96.5%

Euro efficiency

>95.4%

MPPT efficiency

>99%

Genaral data

Dimensions (W / D / H)

345*162*384 mm

Net weight

17Kg

Operating temperature range

–25 °C ~ +60 °C

Noise emission (typical)

≤ 25 dB(A)

Power consumption at night

0 W

Electrical isolation

Transformer-less

Cooling concept

Natural cooling

IP Code

IP65

Communication

RS-485/RS-232
